SensorsandEmbeddedEquipmentScaleUnitsNCLinearScales(LinearEncoders)Linearencodersdetecttheamountoflinearmovementanddisplacementandcanoutputasdigitaldata.TheyareusefulforpositioningandcontrollingCNCmachines,semiconductormanufacturingequipment,inspectionequipment,etc.ABSOLUTELinearScale(separatetype)ABSST700Separate-typeABSOLUTEscalesusingtheelectromagneticinductionmethod.Non-contactdetectionisoptimalforhigh-speedandhigh-accelerationdevicessuchaslinearmotors.•Detectionmethod:Electromagneticinduction•Maximumeffectiverange:6000mm•Resolution:0.1µm•Maximumresponsespeed:5000mm/sABSOLUTELinearScale(separatetype)ABSST1300Thetelecentricimagingopticalsystemisusedfordetectingposition.OutstandingrobustnessagainstcontaminationandGAPallowancecomparedtoearlieropticaltypes.Therearethreetypesofattachmentmethodsavailableaccordingtotheapplication.•Detectionmethod:Optical•Maximumeffectiverange:12000mm•Resolution:0.001µm•Maximumresponsespeed:8000mm/sProductcatalogE13005ProductcatalogE13005IncrementalLinearScale(separatetype)IncrementalLinearScale(separatetype)ST36ST46-EZAAhigh-accuracymodelthatoutputsa2-phasesinewaveof4µmsignalperiod.Therearefourtypesofoutputsignalformsselectableforyourspecifications.•Detectionmethod:Optical•Maximumeffectiverange:3000mm•Resolution:0.01µm•Maximumresponsespeed:1200mm/sIncludesanautomaticadjustmentfunctionforthesignal(EZAfunction)atthepushofabutton.Awiderangeofspecificationsareavailabletobestsuityourapplication(s).Withthe"setupindicator"installedontheconnectorshell,adjustmentwhileattachediseasywithouttheneedofanoscilloscopeorPC.•Detectionmethod:Optical•Maximumeffectiverange:3000mm•Resolution:0.05µm•Maximumresponsespeed:2600mm/sProductcatalogE13005ProductcatalogE1300511-10
| <
|
> |
>>
